Marine Batteries |
|
THEREE
DIFFERNT VARIETIES OF BATTERIES SUITABLE
FOR ALL KINDS OF VESSELS AND ALL POWER SUPPLIES
|
12V 90 Ah 380 A |
|
Can
provide starting with engines up to 70 kW |
|
12V 125 Ah 430 A |
|
Can
provide starting with engines up to 105 kW Can provide starting with engines up to 105 kW |
|
12V 200 Ah 690 A |
|
Has
starting power of 600 A at-18º C and 1000 A at +20ºC. Can provide starting with engines up to 190 kW |
NO MAINTENANCE FOR AN OFF-SEASON PERIOD OF 3-6 MONTHS Can be re-used, without being charged, after having been stored for a period of 3-6 months in a dry and cool place at enviromental temperatures. Batteryt must be fully charged prior to long out of season waiting periods. No additional maintanance is required because of very little loss of charge. EXTRA LIFE Cellular plates are of a struce providing extra life. They are designed in form to supply both, the starter motor and the electrical sytem.Cellular plates are of a struce providing extra life. They are designed in form to supply both, the starter motor and the electrical sytem. CAPABILITY OF WORKING AT AN INCLINATION OF 55º It has a property of working even at an incliation of 55º under adverse weather conditions at seas. It owns a special bushing and discharge system preventing owerflow of electrolyte, people being annoyed by gas fumes in its area of operation and damege to orther equipment in the vicinity. |
| BOX DIMENSIONS |
12V 90Ah 380A |
12V 125Ah 430A | 12V 200Ah 690A |
| BOX LENGTH (mm) | 318 | 348 | 518 |
| BOX WIDTH (mm) | 175 | 175 | 291 |
| BOX HEIGTH (mm) | 190 | 270 | 216 |
| BOX TERMINAL POST HEIGHT (mm) | 190 | 290 | 242 |
| DRY (kg) | 16.2 | 23.6 | 44.2 |
| WITH ACID (kg) | 23.5 | 34.3 | 63.0 |
